Hisense 75″ Quantum 120Hz ULED 4K TV

R23999,00

Product
Factory model 75A65GAVT
Factory Qingdao
Description 189cm (75″ ) Direct LED Television
Document
Specifications form version HA220120
Circulation Restricted, internal use only
Status Confirmed
Revision number 1
Date 1/27/2022
Issued by Al
Image display
Panel manufacturer Hisense
Panel model LCM:HD750Y3U72-L7, Open Cell:HV750QUB-E7D
Active display area, horizontal dimension 1649.664mm
Active display area, vertical dimension 927.936mm
Screen size (rounded to nearest integer) 189cm
Screen size (rounded to nearest integer) 927.936mm
Display technology LCD/ LED lit
Backlight source Direct LED
Resolution (Horiz x Vert) 3840X2160
Screen curvature radius –
Colour depth 8bit+FRC
Image refresh frequency 120Hz
Smooth motion rate 240
3D image –
Typical brightness of white 400cd/m2
Native contrast ratio 1400 : 1
Viewing Angle (Horiz / Vert) 178/  178Degrees
Quantum dot Yes
Wide colour gamut Yes
KSF phosphor Yes
UHD Premium No
Response Time 8ms
Connectivity
RF- Radio frequency input 1
AV input 1
AV output 0
USB interface type 3.0 (Qty / List….) 1
USB interface type 2.0 (Qty / List ….) 1
Optical digital audio output (SPDIF) 1
Earphone jack 1
HDMI ports
HDMI inputs 4
HDMI type 8K@60Hz No
HDMI type 4K@60Hz with HDCP version 2.2 YES
HDMI 2.1  compliant input YES
Enhanced Audio Return Channel ( eARC) YES
CEC- Consumer Electronics Control via HDMI Yes
Smart TV
Ethernet port (RJ45 connector) 1
Wi-Fi  protocols IEEE 802.11 {b, g, n, ac, ad, ..} a, b, g, n, ac
Wi-Fi bands 2.4/5.0GHz
DLNA compliance Yes
Bluetooth / BT version Yes / 5.0
Anyview (Screen mirroring) Yes
Catch-up TV services Iview,  SBS on Demand,  7 Plus, 9 Jumpin
(Tenplay available from Playsore)
UHD (4k) streaming Yes
Installed Applications {List ……} Netflix/Youtube/Prime Video……
Freeview Plus – HbbTV 2.0 Yes
Web browser [Chrome | Opera | Other] Odin
Digital TV reception
Television system (DVB-T / DVB-T2) Yes / Yes
Video decoder (MPEG2 / MPEG 4) Yes / Yes
AC3 Surround sound decoder Yes
AS 4599.1 compliance Yes
AS 4933.1 compliance Yes
LCN- Logical channel number and DTV Service name support Yes
Teletext  / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX Yes / Yes / Yes
Subtitles Yes
RF Signal strength indicator Yes
RF Signal quality indicator Yes
RF Bit error rate indicator Yes
EPG- Electronic programming guide, 7 days for all services Yes
Audio description (vision impairment aid) Yes
Parental rating lock Yes
Analogue TV reception
Colour-Sound systems in VHF band PALSECAM, B/G, D/K, I
Colour-Sound systems in UHF band PALSECAM, B/G, D/K, I
Stereo sound decoder {A2, Nicam, ….} No
Teletext  / Teletext signal interruption (TAB compliant) / 16 : 9  TLTX No/ No/ No
Subtitles Yes
Image processing
Backlight control Yes
Light sensing Yes
Dynamic backlight control Yes
Frame rate control No
Variable Refresh Rate (VRR) Yes
FreeSync Yes
Auto Low Latency Mode for VRR Yes
Local dimming/ controllable zones Yes
Zoom function settings Automatic/ 16:9/ 4:3/ Panoramic/
Movie Zoom/ Direct
1:1 Pixel mapping No
HDR – High Dynamic Range for luminance (DMP / Netflix / HDMI) Yes/ YES / YES
HDR system (HDR10 / HDR10+ / Dolby Vision) Yes/ YES / YES
HLG (Hybrid Log-Gamma) for HDR YES
HEVC (H.265) decoder Yes
Dual image (PIP / POP) No/ No
Motion enhancement and compensation (MEMC) Yes
Input lag NO
Sound
Audio power output per channel 15Watt
Number of speakers (Tweeter / Midrange / Woofer) 0 /2 /1
Automatic volume level (AVL) Yes
Audio equalizer Yes
Dolby Digital Yes
Audio enhancement -Type {SRS, BBE, SAP, DBX-TV….} Dolby ATMOS
Lip-sync  adjustment Yes
Features
On/off timer Yes
Power off if no signal Yes
Sleep timer Yes
Program lock Yes
OSD transparency control Yes
User interface VIDAA U6
Software version OSD indication Yes
Legal requirements: Disclaimer / Acceptance of Terms Yes / Yes
Favourite channels list Yes
Electronic point of sales (E-POS) Yes
OTA- Over the air software updates Yes
Voice command Yes
Screen mirroring {Miracast, Anyview Cast, …} Anyview Cast
Smartphone remote control application {Rremote Now, …} Yes/Vidaa App(Remote Now)
Replaceable demo video for Store mode Yes
Remote control via serial port No
USB media player
Personal Video Recorder Yes
Time Shift Yes
DTV Recording (EPG scheduling / start from Standby ) Yes / Yes
DivX decoder No
MPEG4 (H.264) / H.265 decoder Yes / Yes
DMP- Digital media player content (Music / Video / Photos / Text) Yes / Yes / Yes / No
DMP Auto-play No
DMP for UHD content via USB Yes
DMP File allocation table (FAT / FAT32 / exFAT / NTFS) Yes / Yes  / No / Yes
PVR  File allocation table (FAT / FAT32 / exFAT / NTFS) Yes / Yes / No / Yes
Hotel lock
Protected Hotel lock submenu (Password / fixed code) No / Yes
Clone function for programs, sound and image settings. Yes
Sub-menu lock, including tuning lock Yes
Keyboard lock Yes
Maximum volume lock Yes
Power on volume Yes
Power on, apply default sound/image settings No
Power on source selection Yes
Power on RF channel selection Yes
Power on mode (On / Standby / Last) Yes / Yes / Yes
Inputs access (Enable / Disable) Yes
Hardware
Processor / Cores MT9900AAAQPC / 4
Dual Tuner No
Colour (Front bezel, rear, stand) Black / Black /  Black
Speakers mounted in enclosure Yes
Mains  power switch No
Swivel base No
Compact packaging Yes
Supply  range [Voltage / Frequency ] 100 ~ 240V，50Hz/60Hz
Standby consumption < 0.5W
Maximum time delay Power On to sound an image 50sec
Installation
Stand area (Width / Depth) 1143×377 mm
Wall mount dimensions (Horiz x  Vert) 400×300 mm
Wall mount, screw thread M6/10 mm
VESA compliance Yes
Detachable power cord Yes
Power cord length 200 cm
Accessories
Remote controller (Technology / Part number ) IR /ERF3G80H(0012)
Battery (size / quantity) AAA / 2
User manual (Available online) / Quick setup guide (Print) 1 / 1
Warranty [In User manual | In separate sheet] In separate sheet
Skype camera (Qty / Part number) –
3D glasses type  [Passive | Shutter] / Link [RF | IR | BT] –
3D glasses (Qty / Part number) –
Dimensions
Dimensions with stand (W x H x D) 1675×1033×377 mm
Dimensions without stand (W x H x D) 1675×960×78 mm
Carton box dimensions (W x H x D) 1865×179×1146 mm
Net weight (with stand / without stand) 28.7Kg/27.9Kg
Gross weight 41.3 Kg
Container load (20ft / 40ft / 40ft HC) 80/164/164
Licensing and certification
EMC- Electromagnetic Compatibility Yes
CB- Electrical safety Yes
HDMI Yes (Hisense internal test)
Dolby Digital Yes
MEPS- Test report Yes
ROHS No
Electrical safety  conformity for Australia Yes
Documentation
Panel specifications Yes
Initial specifications (input form) Yes
Confirmed product specifications Yes
List of DMP formats for audio and video Yes (QSG)
Documentation
CB report and certificate Yes
EMC report and certificate Yes
Power cord, plug and connector Australian safety approval Yes
SKU: 75U7H Categories: ,
  • Full Array Local Dimming
  • Quantum Dot Colour
  • 120Hz Ultra Motion
  • Dolby Vision IQ
  • HDR 10+ Adaptive
  • Game Mode Pro
  • Hands-Free Voice Remote
